SL-S050075 EuroBrite™ Small Spot Light

The SL-S050075 is a small EuroBrite spot light for general machine vision inspection where high intensity is needed at a competitive price. An IP67 sealed housing keeps water and dust out, so the light goes straight onto a wash-down line without an enclosure.

The head accepts a standard coded 5-pin M12 cable, so it connects with cordsets already stocked for the sensors and cameras on the same machine. At 92.53 g it carries on a moving axis or a robot wrist without meaningful load.

Strobe control allows up to five times overdrive, giving the extra light needed to freeze fast-moving parts at short exposure, and trigger-to-pulse latency of 10 microseconds keeps the flash tight to the camera trigger. Analogue intensity control from 0.7 V to 10 V sets brightness from 10 to 100 per cent, so exposure is tuned in software. The SL-S050075 range covers white and ten wavelengths from 455 nm to 940 nm, runs on 24 V nominal from 0 to 60 degrees C, and is certified to CE, RoHS and IEC 62471.
