VisioCablePro®
Precision measurement and sample preparation systems for cable and wire manufacturing — from diameter and concentricity measurement to cut and strip sample quality control.
VisioCablePro® is a specialist brand from iiM GmbH focused on offline quality assurance for cable and wire manufacturing. Their systems address two areas of the production process: offline geometrical measurement of cable cross-sections, insulation thicknesses, other quality-relevant parameters, and sample preparation for cross-section and cut-strip quality analysis. Exaktera represents VisioCablePro® for the global cable manufacturing market.
Offline cable measurement
VisioCablePro® measurement systems cover outer diameter, ovality, concentricity, layer thickness, and many other quality relevant parameters for a wide range of cable types — from fine wire assemblies to heavy industrial cable. Offline (laboratory) configurations are available, with systems capable of measuring across the full production range without changeover.
Measurement data is logged and trended by product and batch, providing the production record required for process control, customer documentation and quality system compliance. Where the measurement result needs to feed back into a production alarm or reject system, VisioCablePro® systems provide the interface.
Precise sample preparation
VisioCablePro® sample preparation equipment handles the conductor removing, cutting, and stripping steps required before cross-section microscopy and inspection. These sample preparation devices minimise operator-to-operator variation in the most critical quality control parameters — cutting angle, sample thickness and, consequently, sample quality all influence what is visible under the microscope and how borderline cases are assessed.
Simple and precise preparation effectively standardises every sample, making cross-section results comparable across operators, shifts and sites. The result is a quality record that holds up to customer and regulatory scrutiny — and an inspection process that does not depend on the most experienced operator being on shift.
Common questions about cable quality measurement
Which cable types do VisioCablePro® systems measure?
Systems cover single-conductor wire, multi-core cable, coaxial cable, screened cable, armoured cable and fibre-optic cable. The measurement principle is non-contact optical, so conductor material, insulation type and surface finish do not affect measurement capability. Contact us with your cable range to confirm compatibility.
What standards do the systems support?
VisioCablePro® systems generate measurement records compliant with applicable standards and customer-specific quality documentation requirements. Traceability to national measurement standards is available for systems requiring calibration records as part of a quality management system.
Automate your cable quality checks.
Our team can assess your cable measurement and sample preparation requirements and specify the right VisioCablePro® system for your production environment.
